Cable Entry Pad | Pass-Through for Ford Transit Roof (No Drill/No Screw)

4.82 out of 5
(11 customer reviews)

US$39.95

This Cable Entry Pad allows to pass a single round cable (antenna, LED, etc.) through the roof of your Ford Transit without having to drill or screw.

Get US$5.99 discount if purchased in conjunction with the Builder's Package. log in to apply the discount or see the Builder's Package to learn more.
Get US$5.99 discount if purchased in conjunction with the Builder's Package. log in to apply the discount or see the Builder's Package to learn more.
SKU: FOR010 Categories: , Tag:
MPN: FOR010
Brand: FarOutRide

The Ford Transit has several pass-through holes hidden below some of the roof plugs, located as follows (marked as #2):

Ford-Transit-Roof-Plugs-(Potential-Water-Leak)

* NOTE: We don’t recommend using the last row of pass-trough holes located at the very back of the Transit with our Cable Entry Pad, because there is not enough space to install the lock nut from inside the van (see step 2).

Use this Cable Entry Pad in any of the Transit’s factory pass-through holes to create a waterproof entry point for a single cable (solar, weBoost antenna, LED, etc.):

Cable Entry Pad Installation (Ford Transit Solar and Antenna Pass-Through Roof)-11

The Cable Entry Pad is secured with VHB tape AND a lock nut. The lock nut compresses the VHB tape and creates a waterproof, permanent bond with the roof.

An IP68-rated cable gland provides the seal with the cable.

Cable Entry Pad for Ford Transit (Section View)

Installation


1. Remove The Roof Plug


You can start with a plastic scraper, it’s a bit easier to get the plug to go at first:

Cable Entry Pad Installation (Ford Transit Solar and Antenna Pass-Through Roof)

Pull to remove the plug completely and clean the sealant left behind with isopropyl alcohol:

Cable Entry Pad Installation (Ford Transit Solar and Antenna Pass-Through Roof)-2

All clean! The Cable Entry Pad will cover the primed surface:

Cable Entry Pad Installation (Ford Transit Solar and Antenna Pass-Through Roof)-3

2. Install The Cable Entry Pad


Unscrew the lock nut from underneath the pad and put aside:

Cable Entry Pad Installation (Ford Transit Solar and Antenna Pass-Through Roof)-4

Peel off the release film from the VHB tape:

Cable Entry Pad Installation (Ford Transit Solar and Antenna Pass-Through Roof)-5

Make sure the surface is still clean and apply pressure for 5-10 seconds:

Cable Entry Pad Installation (Ford Transit Solar and Antenna Pass-Through Roof)-6

Install the lock nut inside the van, hand-tight firmly with your fingers then use a 24mm or 15/16″ socket to add about one extra turn (do not use tools and overtorque, this will damage the plastic threads) :

Cable Entry Pad Installation (Screw Lock Nut Inside Van)

3. Install The Cable


Unscrew the sealing nut from the gland (without removing it) and route the cable through the gland:

Cable Entry Pad Installation (Ford Transit Solar and Antenna Pass-Through Roof)-10

Screw the sealing nut (hand-tight, but firmly) to create a waterproof joint:

Cable Entry Pad Installation (Ford Transit Solar and Antenna Pass-Through Roof)-11

At this point the installation is waterproof, but you may choose to add a bead of sealant around the pad/cable for your peace of mind.

Optional: Temporary Plug


Not quite ready to route the cable? That’s OK! You can use our Temporary Plug until you’re ready for the final installation:

Loosen the sealing nut and insert the plug:

Cable Entry Pad Installation (Ford Transit Solar and Antenna Pass-Through Roof)-8

Screw the sealing nut to make a waterproof joint:

Cable Entry Pad Installation (Ford Transit Solar and Antenna Pass-Through Roof)-9

We developed the Cable Entry Pad when installing our motorized tilting weBoost antenna. You might be interested in reading the full write-up:


Compatibility


  • Van Models: Ford Transit (2015-Present).
  • Cable Profile: Round (not flat).

Specifications


  • Outside Dimensions: 1.78in diameter x 1.52in height (45mm x 39mm).
  • Materials:
    • Pad: ASA (Acrylonitrile styrene acrylate).
    • Gland: Nylon.
    • Seal: TPU.
    • Self-Adhesive: 3M VHB Tape.
  • Temperature Resistance: Up to 221F (105°C).
  • UV Resistant.
Cable Entry Pad Specifications (Dimensions)

Shipping


  • Ships From:  British Columbia, Canada.
  • Carrier: Canada Post / USPS.
  • Cost: Actual carrier shipping rate calculated at checkout. You can combine other items from our Store to save on shipping.

wARRANTY, rETURNs & Refund


Warranty: If there is an issue or manufacturing defect, we’ll be happy to send you another one free of charge! 🙂

Returns & Refund: You are responsible of shipping the product back to us (including the shipping fees associated with it) for the following reasons:

  • Ordered by mistake or if you changed your mind.
  • Incompatibility (please check “Compatibility” section before ordering).

ABOUT THIS PRODUCT


Do It Yourself.

We wanted a better cable entry point for the Ford Transit, so we made one.

This is an homemade product.

Each Cable Entry Pad is individually 3D printed and assembled by us. This is not a mass-produced product. This is a crafted, hand-made product.

Low Volume.

We created this product for our own needs, to make just a few units. There is no way for us to ramp up the production and lower the price, unless we take it to injection molding manufacturing but that’s a whole another level we’re not considering at the moment.
