3D Model Design

Ford Transit Virtual Butter 3D Model

3D Model Design

Interactive 3D CAD Model:

  • ROTATE: Left-Click
  • PAN: Right-Click
  • ZOOM: Mouse Scroll Wheel
  • HIDE/SHOW: Right-Click (contextual menu)

Floor Plan & Interior Layout (PDF):

Side View | Driver Layout
FarOutRide Camper Van Floor Plan and Interior Layout PDF (V1, rev A, page 1) (600px)
Side View | Passenger Layout
FarOutRide Camper Van Floor Plan and Interior Layout PDF (V1, rev A, page 2) (600px)
Top View | Floor Plan
FarOutRide Camper Van Floor Plan and Interior Layout PDF (V1, rev A, page 3) (600px)
Rear & Front View | Garage & Kitchen
FarOutRide Camper Van Floor Plan and Interior Layout PDF (V1, rev A, page 4) (600px)

Minimum Price: $10.00

The pdf download includes all the views shown above. Printable on 8.5" x 11" (letter) sheet.
